Repeatability:±0.005(mm)
Ball Screw Lead:5/10/20/32(mm)
Maximum Speed:200/400/800/1280(mm/s)
Maximum Payload (Horizontal):120/95/50/35(kg)
Maximum Payload (Vertical):40/25/15/12(kg)
Rated Thrust:2563/1281/640/400(N)
Stroke/Pitch :800-2200 / 50 mm pitch
*When the stroke is over 1700 mm, the run-off the ball screw will occur.We recommend to low down the working speed under this circumstances.
*Acceleration and deacceleration value is set 0.2 second.
