System Platform | Benchtop |
Welding Chamber Safety Certification | Class 1 |
iWeld Lasing System | Class 4 |
Wavelength | 1064nm |
Pulse Energy | 0,1 - 180 Joules |
Maximum Peak Power | up to 11.0 kW |
Internal Power Supply | 400 Volt |
Average Power | 60 Watts / 80 Watts |
Pulse Length | 0,1 - 30 Milli-seconds |
Pulse Frequency | 0,5 - 50 Hz |
Burst / Speed Welding | Optimized to Energy Values |
Beam Diameter1 | 0,05mm - 2,00mm |
Cooling System | Internal Water-To-Air |
Supply Circuit | 120V (± 10%), 50/60Hz 208V (± 5%) / 230V (± 10%), |
Binocular Microscope | 15x (optional 25x, 40x) |
Chamber Illumination System | LED Natural Lighting (Dual) |
Soft-Touch™ Resonator Technology | Optional |
Pulse Performance Profile Technology2 | Exclusive Integrated Software |
Programming Memory | 79 Text Cells |
Program Application Settings | Yes |
Automatic Sleep Mode | Exclusive Integrated Software |
Parameter Adjustment Features | External Touchscreen |
Preventative Maintenance Alert Software | Yes |
User "Direct Connect" Software | EZ-LINK |
Language Display Options3 (Additional Languages Available Upon Request) | Yes |
Motorized Beam Expander | Yes |
Shield Gas Supply | Integrated “Soft Flow” Nozzle |
Inert Gas Welding Chamber Adjust Valve | Yes |
Welding Chamber Dimensions | 10”L x 20”W x 9”H |
“Footprint” Dimensions
| 33”L x 21”W x 16”H |
Weight (Unpackaged) | 125 lbs / 57 Kg |
Warranty Coverage (Parts & Labor) | As Quoted |
Laser Safety Certification Compliance | FDA(CDRH), UL, CSA, CE |
Country of Origin (Parts & Assembly) | Made In USA |
