Repeatability:±0.01(mm)
Ball Screw Lead:2/5/10/20(mm)
Maximum Speed :100/250/500/1000(mm/s)
Maximum Payload (Horizontal):30/30/15/10(kg)
Maximum Payload (Vertical):10/10/5/2.5(kg)
Rated Thrust:854/341/170/85(N)
Stroke/Pitch :50-600 / 50 mm Pitch.
* If payload near maximum , it requires to collocate externally with auxiliary guideway for bearing radial load.
* Acceleration and deacceleration value is set 0.2 second.
