Repeatability:±0.005(mm)
Ball Screw Lead:5/10/25/40(mm)
Maximum Speed:250/500/1250/2000(mm/s)
Maximum Payload (Horizontal):150/150/105/43(kg)
Maximum Payload (Vertical):55/45/20/12(kg)
Rated Thrust:2563/1281/640/320(N)
Stroke/Pitch :50-1500 / 50 mm pitch
*When the stroke is over 900mm, the run-out of the ball screw will occur .We recommend to low down the working speed under this circumstances.
*Acceleration and deacceleration value is set 0.2 second.
