Repeatability：±0.005(mm)
Ball Screw Lead：5/10/20/32(mm)
Maximum Speed：250/500/1000/1600(mm/s)
Maximum Payload (Horizontal)：110/88/40/30(kg)
Maximum Payload (Vertical)：33/22/10/8(kg)
Rated Thrust：1388/694/433/347(N)
Stroke/Pitch ：50-1050/ 50 mm pitch
*When the stroke is over 750mm, the run-out of the ball screw will occur .We recommend to low down the working speed under this circumstances.
*Acceleration and deacceleration value is set 0.4 second.
