Repeatability:±0.005(mm)
Ball Screw Lead:5/10/20/32(mm)
Maximum Speed:250/500/1000/1600(mm/s)
Maximum Payload (Horizontal):110/88/40/30(kg)
Maximum Payload (Vertical):33/22/10/8(kg)
Rated Thrust:1388/694/347/217(N)
Stroke/Pitch :50-1050/ 50 mm pitch
*When the stroke is over 750mm, the run-off the ballscrew will occur.We recommend to low down the working speed under this circumstances.
*Acceleration and deacceleration value is set 0.2 second.
