SPEC
Repeatability：±0.005(mm)
Ball Screw Lead：2/6/12/20(mm)
Maximum Rotating speed：3600 / 3600 / 3600 / 3600 rpm
Maximum Speed ：120/300/720/1200(mm/s)
Maximum Payload (Horizontal)：30/25/22/10(kg)
Maximum Payload (Vertical)：10/6/4/3(kg)
Rated Thrust：854/285/142/85(N)
Stroke/Pitch ：50-1000 / 50(mm)
